Mission 1 to the Moon

LISTER will characterize heat flow from the interior of the Moon by measuring the thermal gradient and conductivity of the lunar subsurface. It will take several measurements to a 2-3 meter final depth using its pneumatic drilling technology with a custom heat flow needle instrument at its tip.

The Lunar PlanetVac will demonstrate pneumatic sample collection of lunar regolith by collecting and sorting regolith within its sample collection chamber. Upon deployment to the surface, PlanetVac will fire a blast of gas into the lunar surface. In a matter of seconds, the surface regolith would be lofted to a collection chamber for visual (camera) inspection. Additional gas jets within the sorting station will perform sieving. The sorting station includes material coupons to test regolith dust adhesion and efficiency of gas jets as a cleaning agent. In comparison to alternative sample collection methods, such as robotic arms, PlanetVac will demonstrate a fast and low cost, low mass solution.

NGLR will support the determination of the distance between Earth and the Moon by reflecting very short laser pulses from Earth-based Lunar Laser Ranging Observatories (LLROs) and measuring the laser pulse transit time to the Moon and back. NGLR will greatly improve the data that is still being obtained from the Apollo era retroreflectors and will support sub-millimeter range measurements. The analysis within the Lunar Laser Ranging  (LLR) program will improve our understanding of the inner structure of the Moon, address modified theories of gravitation and dark matter, and further research in lunar physics and cosmology.

RAC will determine how lunar regolith sticks to a range of materials exposed to the Moon’s environment throughout the lunar day. RAC will measure accumulation rates of lunar regolith on the surfaces of several materials (e.g., solar cells, optical systems, coatings, and sensors) through imaging to determine their ability to repel or shed lunar dust. The data captured will allow the industry to test, improve, and protect spacecraft, spacesuits, and habitats from abrasive regolith.

RadPC will demonstrate a computer that can recover from faults caused by ionizing radiation. Several RadPC prototypes have been tested aboard the ISS and Earth-orbiting satellites, but we’ll provide the biggest trial yet by demonstrating the computer’s ability to withstand space radiation as it passes through the Earth’s radiation belts, while in transit to the Moon, and on the lunar surface.

EDS is an active dust mitigation technology that uses electric fields to move and prevent hazardous lunar dust accumulation on surfaces. EDS is designed to lift, transport, and remove particles from surfaces with no moving parts. They will run multiple tests to demonstrate the feasibility of the self-cleaning glassed and thermal radiator surfaces on the Moon. In the event, the surfaces do not receive dust during landing, the EDS has the capability to re-dust itself using the same technology.

LEXI will capture a series of X-ray images to study the interaction of solar wind and the Earth’s magnetic field that drives geomagnetic disturbances and storms. Deployed and operated on the lunar surface, this instrument will provide the first global images showing the edge of Earth’s magnetic field for critical insights into how space weather and other cosmic forces surrounding our planet impact Earth.

LMS will characterize the structure and composition of the Moon’s mantle by measuring electric and magnetic fields. This investigation will help determine the Moon’s temperature structure and thermal evolution to understand how the Moon has cooled and chemically differentiated since it formed.

LuGRE will receive and track signals from the GPS and Galileo navigation satellite constellations during the Earth-to-Moon transit and throughout a full lunar day on the Moon’s surface. This demonstration will help characterize and extend Global Navigation Satellite System (GNSS)-based navigation and timing to lunar orbit and the Moon’s surface, lunar spacecraft with accurate position, velocity, and time estimations autonomously, on board, and in real time.

SCALPSS will use stereo imaging photogrammetry to capture the impact of rocket plume on lunar regolith as our lander descends on the Moon’s surface. The high-resolution stereo images will aid in creating models to predict lunar regolith erosion – an important task as bigger, heavier payloads are delivered to the Moon in close proximity to each other.
